UXV 700I EPS DELIVERS, DAY IN AND DAY OUT.

When it comes to hard work, UXV 700i EPS gets the job done.



Powered by KYMCO’s smooth 45 horsepower engine, which features a new and improved automatic CVT-Drive system, including all-important active engine braking. Off road the UXV really feels at home, with plenty of ground clearance, a simple ‘push button’ two-wheel-drive / four-wheel-drive activation and independent dual A-Arm suspension front and rear.



Bred to work, the UXV has a generously sized tipping cargo bed and a hefty 550kg tow capacity to get more done in your workday. KYMCO is made tough in Taiwan and supported by an industry leading 5 year warranty, which guarantee’s A-Grade durability.



Visit your local dealer and see why your next side by side on the farm will be a KYMCO.

Features

Powerful 45HP four-stroke engine

659cc, SOHC, liquid-cooled four-stroke engine with new EFI mapping provides plenty of power

Smooth electronic power steering

Electronic power steering reduces rider fatigue and provides increased manoeuvrability

Advanced electronic fuel injection

Electronic fuel injection delivers easier starting, smoother power and increased efficiency

High / low range selector

CVT automatic transmission with high / low range selector

Active engine braking

Active engine braking retards excess speed

Selectable drive modes with diff lock

Diff lock with push button selectable 2WD / 4WD will master any terrain

Superior braking performance

Front and rear hydraulic disc brakes with braided lines provide superior braking

Parking brake

Shaft mounted parking brake for safe parking while the operator is off the machine

Broad halogen lighting

Twin front halogen head lamps with high / low beam provide a broad spread of light

Rear halogen brake lamps

Rear halogen brake lamps for enhanced visibility

Bright LED front position lamps

LED front position lamps increase vehicle visibility

Digital instrumentation

Backlit digital instrument display

Front and rear independent suspension

Dual A-Arm front and rear independent suspension provides 12 inches of ground clearance

Adjustable shock absorbers

Kaifa gas-reservoir shock absorbers offer pre-load, compression and rebound adjustment

STEEL WHEELS

Durable 12 inch black steel wheels

CONVENIENT 12V DC OUTLET AND USB PORT

Sealed in dash 12V DC outlet and USB port to charge your devices or run a spotlight

ROLL CAGE

Redesigned roll cage with increased headroom and added protection

AUTOMOTIVE STYLE 3-POINT SHOULDER SEAT BELTS

3-point shoulder seat belts for occupant protection with safety interlock

SEAT BELT REMINDER LAMP

Instrumentation features seat belt reminder warning lamp

INTEGRATED STORAGE

Under-hood, under-seat and lockable glove box storage

TILTING CARGO BED

Gas assisted tilting cargo bed with dual control levers on driver and passenger side

LARGER TYRE SIZE

MAXXIS 25×8-12 inch front and 25×10-12 inch rear tyres feature aggressive tread blocking

UNDER SIDE SKID PLATES

Front brush guard and under side skid plates deflect debris from vital components

SIDE NETTING

Side netting protects occupants from side intrusion

Factory warranty

Five year factory warranty program* supported by a national dealer network

Specifications

Engine
EngineSOHC, liquid-cooled, four-stroke
Displacement695cc
Power45 HP @ 6500 RPM
Bore x Stroke102 x 85 mm
Compression ratio10.5:1
Fuel systemElectronic Fuel Injection
IgnitionECU
Starting systemElectric
TransmissionCVT automatic with dual range, reverse gear and active engine braking
Final drivePush button selectable 4WD with locking front differential, Shaft
Suspension
Front suspensionIndependent dual A-Arm with adjustable Kaifa gas-reservoir shock absorbers
Rear suspensionIndependent dual A-Arm with Kaifa gas-reservoir shock absorbers
Front tyre size25 x 8 - 12 inch / Steel wheels
Rear tyre size25 x 10- 12 inch / Steel wheels
Front brakesDual hydraulic disc, 202 mm
Rear brakesSingle hydraulic disc, 200 mm
Capacity
Cargo bed size1210 mm x 820 mm x 310 mm
Cargo bed payload200 kg
Tow550 kg
Size / Weight
Length x Width x Height2870 mm x 1500 mm x 1850 mm
Wheelbase1910 mm
Ground clearance300 mm
Fuel capacity32 l
Dry weight 543 kg
Other
ColourWhite
Warranty5 year factory program*

*KYMCO products are supported by our 5-year factory warranty program. The program provides warranty for a period of two years from the date of purchase. However, if you have your vehicle serviced exclusively at an authorised dealer and retain an accurate service history, you will be eligible for a further three year extension. For more details, contact your local KYMCO dealer.
